SHACMAN M3000 6X2 van truck

Complete vehicle

Model

SX1206GK549

Drive type

6X2

Wheel base(mm)

1800+5400

Overall dimension(mm)

12000X2550X3950

Curb weight(Kg)

10300

Load capacity(Kg)

20000

Cabin

High roof,one and half rows,luxury configuration,

2,3 passengers allowable,with double bunkers,A/C

Engine

Model

WP6.245E40

Max.output (kw/HP)

180/245

Max.torque (N•m)

900@1100~1700rpm

Displacement (ml)

6750

Emission standard

Euro IV

Description

In-line, 6 cylinders,water cooled,4 strokes,turbo charged,inter-cooled,electric control,high pressure,

common rail,diesel engine

Gear box

9JS119TB,manual,9 forward ＆1 reverse gears

Driving axle

Twin reduction with big torque ratio 3.364,

load capacity 10100Kg

Front axle

Steering axle,load capacity 5000+5000Kg

Quantity of leaf spring

10/10/10+6

Clutch

Diaphragm clutch,pull-type Ø430

Inner trimming

Standard configuration

Air suspension seat

Seat heater

Lumbar support to the driver

Adjustable steering wheel

Electrical system

Standard configuration

CAN bus intellectual electronic control system

New battery box

Start/stop device under the vehicle

Safety

Standard

configuration

Three points safety belt

Automatic clearance adjustment arm,tachometer

Service brake

Dual circuit compressed air brake

Parking brake

Spring energy, compressed air operating on rear wheels

ABS

Provided

Comfortable accessories

Cab four points full floating suspension

Front and rear coil spring

Standard configuration

Cab anti-rolling stabilizing device

Hand accelerator

Electric window

Provided

Chassis

Fuel tank

400L,aluminum fuel tank

Standard configuration

Big tool box

Reinforced rim (with HQ mark)

Three in one lock (Ignition switch, door and fuel tank)

Type specification

11.00R20

Number of tyres

8+1

Max.vehicle speed(km/h)

99

Grade ability(%)

25

Box dimension(mm)

9600X2450X2700
