Changan mini truck with double rows cabin

Vehicle name

Cargo truck

Chassis model

SC1022SEAB6

Weight parameter

Curb weight

（Kg）

1206

Overall dimension (mm)

5175X1600X1910

Load capacity

（Kg）

500~1000

Wheel base

(mm)

3200

Total weight

(Kg)

2020

Cargo box dimension (mm)

2550X1520X375

Engine

Model

JL473QH

Description

4-cylinders,in line,

4-valves,DOHC,

mechanical tappet,

MPI

Max.output power

（KW/HP）

78.5/107

Displacement(ml)

1480

Fuel type

Gasoline

Emission level

Euro 6

Performance

Max. vehicle speed(km/h)

112

Running angle(°)

Approach angle

35

Fuel consumption

(L/100km)

7.1

Departure angle

29

Description of gearbox

Manual,5 forward gears,1 reverse gear

Clutch

Diaphragm spring clutch

Brake system

Hydraulic brake

ABS,OBD

Provided

Specification of tyre

175R14LT 8PR

Quantity of tyres

4+1pcs

Frame

Stamping riveted structure

Number of leaf spring

-/6

Cabin

Double rows,luxury sedan configuration,2+3 passengers allowable,A/C,electric window,central lock,reversing radar

Electric system

12V

Steering type

Left hand drive

Fan heater

Provided
