Cargo truck

JAC superior quality cargo truck 3Ton with diesel Euro 2 engine

New model cabin N721,single row
Engine model HFC4DA1-1 ，Euro 2, 92HP
Box dimension 3630x1900x400mm
Good price,good quality Mobile:0086 15826750255
Product description: JAC superior quality cargo truck 3Ton with diesel Euro 2 engine
INQUIRY

Product brand		JAC
Cabin / Passenger capacity		New model N721,single row,luxury configuration,power clutch,1 passenger + 1 driver,tilting system,MP3,A/C
Chassis	Overall dimension	5495x2000x2320mm (LWH)
	Cargo box dimension	3630x1900x400mm (LWH)
	Curb weight	2350 kgs
	Design load	3000 kgs
	Drive type	4x2
	F/R suspension	1110/1535 mm
	Wheelbase	2800 mm
	Number of axles	2
	Axle-load	1610/2865 kgs
	Approach/Departure angle	20/15°
	Number of leaf spring	8/4+6
	F/R track	1440/1425 mm
	Tire ( No. & specification)	6.50R16 10PR, 6+1pcs
	Max speed	90 km/h
	Brake system	Hydraulic braking
	Steering	Left hand drive with power steering
	Transmission	LC5T255M3,mechanical,5 forward + 1 reverse gears
Engine	Engine model	HFC4DA1-1
	Max.power	68KW(92HP)
	Description	In line,water cooled,four strokes,turbo charged,inter cooled, direct injection,diesel engine
	Rated revolution	3600rpm
	Max torque	225N.m@1800~2200 rpm
	Exhaust	2771 ml
	Emission standard	Euro 2
Cargo van	Material	Carbon steel
	Thickness of front and rear plate	3 mm
	Thickness of side plate	2 mm
	Thickness of bottom plate	3 mm
Painting	Description	With sand blasting,painted with epoxy paint,finished color
Warranty	Year	1
