Chassis model |
QL1250WPFZY |
|
Main dimension |
|
|
Overall dimension(mm) |
9500×2540×3350 |
|
Dimension of dump box(mm) |
6500×2300×1200 |
|
Drive Type |
4X2 Left hand drive |
|
Wheel base (mm) |
4650+1300 |
|
Wheel track(front/rear)(mm) |
2048/1860,1860 |
|
Weight data |
|
|
Curb weight(Kg) |
12500 |
|
Load capacity(Kg) |
30000 |
|
Engine |
|
|
Model |
6HK1-TCH |
|
Description |
In-line,6 cylinders,water cooling & turbo charged,inter-cooling diesel engine |
|
Displacement(L) |
7.79 |
|
Power(kw/HP) |
221/300 |
|
Maximum Torque(N·m) |
980 |
|
Emission level |
Euro 5 |
|
Gearbox |
|
|
Brand |
FAST |
|
Model |
Manual, 9 forward ＆ 1 reverse gears |
|
Axles |
|
|
Front axle load capacity |
7Tons |
|
Rear axle load capacity |
18Tons*2 |
|
The others |
|
|
Cabin |
Single row,two doors,luxury type,with power steering,air conditioner,,central lock,electric window,radio,USB interface |
|
Brake |
Pneumatic brake system,with ABS |
|
Tire type |
295/80R22.5 |
|
Number of spring plate |
9/9+7 |
|
Front /rear overhang(mm) |
1335/1735 |
|
Approach/departure angle(°) |
15/17 |
|
Max.speed(km/h) |
105 |
|
Lift system |
Hydraulic front lift |
|
Thickness of box |
Side 6mm,bottom 8mm |
|
Material of box |
WISCO Carbon Steel Q235 |
